The BIG-IPmanagement interface (MGMT port)is controlled throughSystem settings, not through the Network menu.

SSH access on the management interface is configured here:

System → Configuration → Device → General → SSH Access / SSH IP Allow

This section allows the administrator to:

Enable or disable SSH service

Restrict SSH access to specific IP addresses or subnets

Apply security policies to the management interface

Why the other options are incorrect:

A. Network > Interfaces

Used for data-plane physical interface settings, not management plane SSH restrictions.

B. Network > Self IPs

Controls in-band management or data-plane access, not the dedicated management port.

D. System > Platform

Used for hostname, time zone, LCD contrast, hardware settings — not SSH security on the management port.

Therefore, restricting SSH access to themanagement interfacemust be done under:

✔System → Configuration → Device → General

Which corresponds toOption C.

TheService Check Datedetermines whether a particular software version is allowed to run under the device’s license.

When installing or upgrading TMOS, the installer checks theService Check Datestored in the BIG-IP license file.

If the license date isolderthan the minimum required for the target version, the software installation isblocked.

This check happensspecifically during a software install, not during routine device operations.

Editing virtual servers or system startup do not trigger this validation.

Thus, the enforcement happensduring software installation.

The exhibit shows theCurrent Resource Allocationfor:

CPU

Disk

Memory

In particular, theMemory Allocationbar displays the modules that are currently provisioned.

Memory is the most reliable indicator because BIG-IP allocates memoryonlyto modules that are actively provisioned.

From the exhibit:

MGMT(Management) – always present

TMM(Traffic Management Microkernel) – indicatesLTM is provisioned

GTM– this label indicates that theDNS moduleis provisioned (GTM = Global Traffic Manager, now called DNS)

APM– explicitly shown, indicatingAccess Policy Manageris provisioned

Therefore, the provisioned modules are:

LTM(implied by TMM allocation)

DNS/GTM

APM

This matchesOption C: LTM, DNS, APM.

When installing a HotFix on a BIG-IP device, F5 best practices require:

Installing the base TMOS image on a new, unused boot volume (HD1.2)

This ensures the upgrade happens on a clean volume.

The existing active boot location remains untouched for rollback.

Installing the HotFix onto the SAME new boot volume (HD1.2)

HotFixes must be applied on top of a base version.

They cannot be installed on an empty volume.

They must match the base image version.

Activating the new boot volume (HD1.2)

The system reboots into the updated software stack.

Activation happensafterbase + HotFix installation is complete.

This sequence is exactly shown inOption C:

Install base Image in HD1.2

Install HotFix in HD1.2

Activate HD1.2

Why the other options are incorrect:

A. Install HotFix before base image

Impossible.

HotFix requires an installed base version first.

B. Installing HotFix on HD1.1 (active boot volume)

Not recommended.

Upgrading in-place removes rollback safety.

HotFix cannot be applied cleanly without applying base image first.

D. Activate HD1.2 before installing anything

You cannot activate an empty boot volume.

Activation only occurs after the base + HotFix software is installed.

Port Lockdown controls which ports and protocols aSelf IPwill respond to.

However, certain traffic types bypass Port Lockdown for BIG-IP functionality and routing integrity.

The three types that areNOT affectedby Port Lockdown are:

1. Defined Virtual Server Traffic

Traffic destined to a Self IP that matches aconfigured virtual serveris always accepted by the BIG-IP, regardless of Port Lockdown settings.

This ensures that traffic processing does not break when administrators restrict Self-IP ports.

2. ICMP (Internet Control Message Protocol)

ICMP (such as ping, traceroute responses, etc.) always passes through a Self IP even when Port Lockdown is set to:

Allow Default

Allow None

Allow Custom

F5 allows ICMP for reachability and diagnostic purposes independent of Port Lockdown rules.

3. Centralized Management Infrastructure (CMI)

CMI includes the internal HA services used for:

Device Trust

ConfigSync

Failover

Mirroring

These essential HA communications bypass Port Lockdown to prevent accidental cluster failure.

The well-known port for this traffic isTCP 4353, which is always permitted.

Why the other options are incorrect:

Option A:SSHisrestricted by Port Lockdown unless explicitly allowed.

Option B:Same issue — SSH does not bypass Port Lockdown.

OnlyDefined VS Traffic,ICMP, andCMIbypass Port Lockdown.
