When implementing a new self-signed root certificate authority (CA) for SSL decryption on a Palo Alto Networks firewall, the subordinate CA certificate (which is generated by the firewall) must be imported into the trust stores of all client devices. This ensures that client devices trust the firewall as a valid certificate authority, enabling the firewall to decrypt and re-encrypt SSL traffic.

Importing the subordinate CA certificate into the client devices' trust stores is necessary for those devices to trust the new self-signed root CA and properly handle SSL decryption traffic.

Assigning an Admin Role Profile to a user in a Palo Alto Networks NGFW is used to define granular permissions for management tasks. This allows administrators to control what actions a user can perform on the firewall, such as configuration changes, monitoring, and logging. By assigning different admin roles, you can ensure that users have access only to the areas and tasks they need, enforcing the principle of least privilege.

Comprehensive and Detailed Explanation From Palo Alto Networks Next-Generation Firewall Engineer documents objectives:

According to Palo Alto Networks technical documentation,GlobalProtectis considered the most accurate and preferred method for obtaining user-to-IP address mappings. This is because GlobalProtect requires an explicit authentication event directly with the firewall (or portal/gateway) to establish a connection. Whether the user is internal or external, the GlobalProtect app provides the firewall with consistent, high-fidelity identity data the moment the network interface is initialized.

While the Authentication Portal (formerly Captive Portal) also uses direct authentication, it is often triggered by specific web traffic (HTTP/HTTPS) and is generally used as a fallback for users who cannot be identified through other means. GlobalProtect, conversely, is described as the "best solution" for sensitive environments because it ensures that the mapping is established at the session level and remains persistent as long as the agent is connected. It eliminates the latency and "best-guess" nature of passive methods like Server Monitoring (probing Active Directory logs) or XFF headers, which can be spoofed or stripped by proxies. Because the firewall itself validates the credentials and maintains the tunnel or connection state, the resulting mapping is 100% verified and tied to the specific device's logical interface.

When configuring a Multi-VSYS environment on a Palo Alto Networks firewall, the administrator can manage and restrict the consumption of hardware resources by individual virtual systems usingResource Quotas. This is a critical architectural step to prevent a single VSYS (tenant) from exhausting the firewall's capacity, which could impact other virtual systems on the same physical chassis.

On theResource tabwithin the Virtual System configuration (found underDevice > Virtual Systems), administrators can set specific limits for various policy types and session counts. Valid configurable limits include:

Sessions Limit(to control the total number of concurrent sessions per dataplane).

Security Rules, NAT Rules, andDecryption Rules.

DoS Protection, QoS, and Application Override rules.

VPN Tunnel limits (Site-to-Site and Concurrent SSL VPN tunnels).

Option B is correct becauseDecryption Rulesare specifically listed as a configurable quota. It is important to note that the firewall does not support limitingCPU utilization(Option A) orMemoryon a per-VSYS basis; these resources are dynamically shared based on traffic demand. While you can assign aVirtual Router(Option C) to a VSYS, it is not treated as a "quota" that you limit by quantity in the resource settings. Similarly,Disk space allocation(Option D) is typically managed at the log database level for the entire device or directed to external collectors, rather than being partitioned as a VSYS resource quota.

In Palo Alto Networks PAN-OS, the management interface (MGT) is distinct from the data plane interfaces. Configuration of the management interface is handled under the deviceconfig system hierarchy within the Command Line Interface (CLI). By default, many Palo Alto Networks hardware appliances are set to a static IP address (typically 192.168.1.1), but in dynamic environments or cloud deployments, shifting to DHCP is often necessary for initial onboarding.

The correct command to enable this is set deviceconfig system type dhcp-client. When this command is executed in configuration mode, the firewall changes its management interface behavior from a static assignment to a DHCP client. Once the change is committed, the firewall will send a DHCP Discover packet out of the MGT port to obtain an IP address, subnet mask, and default gateway from a local DHCP server.

It is important to differentiate between deviceconfig (which handles system-level and management plane settings) and network (which handles data plane interfaces like Ethernet1/1). Options C and D are syntactically incorrect for PAN-OS, while Option B does not follow the standard hierarchy for system configuration. For engineers troubleshooting connectivity, verifying this setting via the command show deviceconfig system is a standard step to ensure the management plane is communicating correctly with the network infrastructure.
