SPLK-4001 Questions and Answers

The correct answer is C. Create a plot C using the formula (A/B-l) and add a scale: 100 function to express the rate of change as a percentage.

To calculate the rate of change in latency, you need to compare the current latency (plot A) with the latency a week ago (plot B). One way to do this is to use the formula (A/B-l), which gives you the ratio of the current latency to the previous latency minus one. This ratio represents how much the current latency has increased or decreased relative to the previous latency. For example, if the current latency is 200 ms and the previous latency is 100 ms, then the ratio is (200/100-l) = 1, which means the current latency is 100% higher than the previous latency1

To express the rate of change as a percentage, you need to multiply the ratio by 100. You can do this by adding a scale: 100 function to the formula. This function scales the values of the plot by a factor of 100. For example, if the ratio is 1, then the scaled value is 100%2

To create a plot C using the formula (A/B-l) and add a scale: 100 function, you need to follow these steps:

Select plot A and plot B from the Metric Finder.

Click on Add Analytics and choose Formula from the list of functions.

In the Formula window, enter (A/B-l) as the formula and click Apply.

Click on Add Analytics again and choose Scale from the list of functions.

In the Scale window, enter 100 as the factor and click Apply.

You should see a new plot C that shows the rate of change in latency as a percentage.

To learn more about how to use formulas and scale functions in Splunk Observability Cloud, you can refer to these documentations34.

1: https://www.mathsisfun.com/numbers/percentage-change.html 2: https://docs.splunk.com/Observability/gdi/metrics/analytics.html#Scale 3: https://docs.splunk.com/Observability/gdi/metrics/analytics.html#Formula 4: https://docs.splunk.com/Observability/gdi/metrics/analytics.html#Scale

The chart visualization types that are unaffected by changing the time picker on a dashboard are:

Single Value: A single value chart shows the current value of a metric or an expression. It does not depend on the time range of the dashboard, but only on the data resolution and rollup function of the chart1

List: A list chart shows the values of a metric or an expression for each dimension value in a table format. It does not depend on the time range of the dashboard, but only on the data resolution and rollup function of the chart2

Therefore, the correct answer is A and D.

To learn more about how to use different chart visualization types in Splunk Observability Cloud, you can refer to this documentation3.

1: https://docs.splunk.com/Observability/gdi/metrics/charts.html#Single-value 2: https://docs.splunk.com/Observability/gdi/metrics/charts.html#List 3: https://docs.splunk.com/Observability/gdi/metrics/charts.html

The correct answer is B. A set of data points that all have the same metric name and list of dimensions.

A metric time series (MTS) is a collection of data points that have the same metric and the same set of dimensions. For example, the following sets of data points are in three separate MTS:

MTS1: Gauge metric cpu.utilization, dimension “hostname”: “host1” MTS2: Gauge metric cpu.utilization, dimension “hostname”: “host2” MTS3: Gauge metric memory.usage, dimension “hostname”: “host1”

A metric is a numerical measurement that varies over time, such as CPU utilization or memory usage. A dimension is a key-value pair that provides additional information about the metric, such as the hostname or the location. A data point is a combination of a metric, a dimension, a value, and a timestamp1

According to the Splunk Observability Cloud documentation1, to create a detector, you need the following information:

Alert Signal: This is the metric or dimension that you want to monitor and alert on. You can select a signal from a chart or a dashboard, or enter a SignalFlow query to define the signal.

Alert Condition: This is the criteria that determines when an alert is triggered or cleared. You can choose from various built-in alert conditions, such as static threshold, dynamic threshold, outlier, missing data, and so on. You can also specify the severity level and the trigger sensitivity for each alert condition.

Alert Settings: This is the configuration that determines how the detector behaves and interacts with other detectors. You can set the detector name, description, resolution, run lag, max delay, and detector rules. You can also enable or disable the detector, and mute or unmute the alerts.

Alert Message: This is the text that appears in the alert notification and event feed. You can customize the alert message with variables, such as signal name, value, condition, severity, and so on. You can also use markdown formatting to enhance the message appearance.

Alert Recipients: This is the list of destinations where you want to send the alert notifications. You can choose from various channels, such as email, Slack, PagerDuty, webhook, and so on. You can also specify the notification frequency and suppression settings.

The correct answer is C. Timeshift.

According to the Splunk Observability Cloud documentation1, timeshift is an analytic function that allows you to compare the current value of a metric with its value at a previous time interval, such as an hour ago or a week ago. You can use the timeshift function to measure the change in a metric over time and identify trends, anomalies, or patterns. For example, to identify the servers where utilization has increased the most since last week, you can use the following SignalFlow code:

timeshift(1w, counters(“server.utilization”))

This will return the value of the server.utilization counter metric for each server one week ago. You can then subtract this value from the current value of the same metric to get the difference in utilization. You can also use a chart to visualize the results and sort them by the highest difference in utilization.

The correct answer is C. 401 (UNAUTHORIZED).

According to the web search results, a 401 (UNAUTHORIZED) error message is indicative that there is a misconfigured realm or access token when installing OpenTelemetry Collector1. A 401 (UNAUTHORIZED) error message means that the request was not authorized by the server due to invalid credentials. A realm is a parameter that specifies the scope of protection for a resource, such as a Splunk Observability Cloud endpoint. An access token is a credential that grants access to a resource, such as a Splunk Observability Cloud API. If the realm or the access token is misconfigured, the request to install OpenTelemetry Collector will be rejected by the server with a 401 (UNAUTHORIZED) error message.

Option A is incorrect because a 403 (NOT ALLOWED) error message is not indicative that there is a misconfigured realm or access token when installing OpenTelemetry Collector. A 403 (NOT ALLOWED) error message means that the request was authorized by the server but not allowed due to insufficient permissions. Option B is incorrect because a 404 (NOT FOUND) error message is not indicative that there is a misconfigured realm or access token when installing OpenTelemetry Collector. A 404 (NOT FOUND) error message means that the request was not found by the server due to an invalid URL or resource. Option D is incorrect because a 503 (SERVICE UNREACHABLE) error message is not indicative that there is a misconfigured realm or access token when installing OpenTelemetry Collector. A 503 (SERVICE UNREACHABLE) error message means that the server was unable to handle the request due to temporary overload or maintenance.

The correct answer is D. gRPC (4317), SignalFx (9080), Fluentd (8006).

According to the web search results, these are the default ports for the corresponding components in the OpenTelemetry Collector. You can verify this by looking at the table of exposed ports and endpoints in the first result1. You can also see the agent and gateway configuration files in the same result for more details.

1: https://docs.splunk.com/observability/gdi/opentelemetry/exposed-endpoints.html

According to the Splunk Observability Cloud documentation1, lag is a rollup function that returns the difference between the most recent and the previous data point values seen in the metric time series reporting interval. This can be used to measure the time delta between a data point being sent and a data point being received, as long as the data points have timestamps that reflect their send and receive times. For example, if a data point is sent at 10:00:00 and received at 10:00:05, the lag value for that data point is 5 seconds.

The correct answer is D. Each data marker represents the sum of API calls in the hour leading up to the data marker.

The metric demo.trans.count is a cumulative counter metric, which means that it represents the total number of API calls since the start of the measurement. A cumulative counter metric can be used to measure the rate of change or the sum of events over a time period1

The chart below shows the metric demo.trans.count with a one-hour rollup and a line chart type. A rollup is a way to aggregate data points over a specified time interval, such as one hour, to reduce the number of data points displayed on a chart. A line chart type connects the data points with a line to show the trend of the metric over time2

Each data marker on the chart represents the sum of API calls in the hour leading up to the data marker. This is because the rollup function for cumulative counter metrics is sum by default, which means that it adds up all the data points in each time interval. For example, the data marker at 10:00 AM shows the sum of API calls from 9:00 AM to 10:00 AM3

To learn more about how to use metrics and charts in Splunk Observability Cloud, you can refer to these documentations123.

1: https://docs.splunk.com/Observability/gdi/metrics/metrics.html#Metric-types 2: https://docs.splunk.com/Observability/gdi/metrics/charts.html#Data-resolution-and-rollups-in-charts 3: https://docs.splunk.com/Observability/gdi/metrics/charts.html#Rollup-functions-for-metric-types

The correct answer is D. Mean (Transformation).

According to the web search results, a mean transformation is an analytic function that returns the average value of a metric or a dimension over a specified time interval1. A mean transformation can be used to smooth a very spiky metric, such as cpu.utilization, by reducing the impact of outliers and noise. A mean transformation can also help to see if the metric is trending up or down over time, by showing the general direction of the average value. For example, to smooth the cpu.utilization metric and see if it is trending up over time, you can use the following SignalFlow code:

mean(1h, counters(“cpu.utilization”))

This will return the average value of the cpu.utilization counter metric for each metric time series (MTS) over the last hour. You can then use a chart to visualize the results and compare the mean values across different MTS.

Option A is incorrect because rate/sec is not an analytic function, but rather a rollup function that returns the rate of change of data points in the MTS reporting interval1. Rate/sec can be used to convert cumulative counter metrics into counter metrics, but it does not smooth or trend a metric. Option B is incorrect because median is not an analytic function, but rather an aggregation function that returns the middle value of a metric or a dimension over the entire time range1. Median can be used to find the typical value of a metric, but it does not smooth or trend a metric. Option C is incorrect because mean (by host) is not an analytic function, but rather an aggregation function that returns the average value of a metric or a dimension across all MTS with the same host dimension1. Mean (by host) can be used to compare the performance of different hosts, but it does not smooth or trend a metric.

Mean (Transformation) is an analytic function that allows you to smooth a very spiky metric by applying a moving average over a specified time window. This can help you see the general trend of the metric over time, without being distracted by the short-term fluctuations1

To use Mean (Transformation) on a cpu.utilization metric, you need to select the metric from the Metric Finder, then click on Add Analytics and choose Mean (Transformation) from the list of functions. You can then specify the time window for the moving average, such as 5 minutes, 15 minutes, or 1 hour. You can also group the metric by host or any other dimension to compare the smoothed values across different servers2

To learn more about how to use Mean (Transformation) and other analytic functions in Splunk Observability Cloud, you can refer to this documentation2.

1: https://docs.splunk.com/Observability/gdi/metrics/analytics.html#Mean-Transformation  2: https://docs.splunk.com/Observability/gdi/metrics/analytics.html

The correct answer is B. Adding logging into the metrics receiver pipeline.

The logging exporter is a component that allows the OpenTelemetry Collector to send traces, metrics, and logs directly to the console. It can be used to diagnose and troubleshoot issues with telemetry received and processed by the Collector, or to obtain samples for other purposes1

To activate the logging exporter, you need to add it to the pipeline that you want to diagnose. In this case, since you are experiencing issues with a new receiver for metrics, you need to add the logging exporter to the metrics receiver pipeline. This will create a new plot that shows the metrics received by the Collector and any errors or warnings that might occur1

The image that you have sent with your question shows how to add the logging exporter to the metrics receiver pipeline. You can see that the exporters section of the metrics pipeline includes logging as one of the options. This means that the metrics received by any of the receivers listed in the receivers section will be sent to the logging exporter as well as to any other exporters listed2

To learn more about how to use the logging exporter in Splunk Observability Cloud, you can refer to this documentation1.

1: https://docs.splunk.com/Observability/gdi/opentelemetry/components/logging-exporter.html 2: https://docs.splunk.com/Observability/gdi/opentelemetry/exposed-endpoints.html

According to the Splunk O11y Cloud Certified Metrics User Track document1, cloning a detector creates a copy of the detector that you can modify without affecting the original detector. You can change the metric, filter, and signal settings of the cloned detector. However, the new signals that you add to the cloned detector will not be reflected in the original detector, nor in the original chart that the detector was based on. Therefore, option D is correct.

Option A is incorrect because the new signals will not be reflected in the original detector. Option B is incorrect because the new signals will not be reflected in the original chart. Option C is incorrect because you can monitor all of the new signals that you add to the cloned detector.
