From the exhibits:

Interface“APs”is a VLAN sub-interface onfortilinkwith IP10.10.100.254/24and a DHCP server scope 10.10.100.1–10.10.100.253.

This VLAN is assigned toport1on the managed FortiSwitch for FortiAPs.

The interface config showsonly allowaccess ping—Security Fabric Connection is not enabled.

In LAN Edge designs, FortiAPs connected through FortiSwitch are discovered and managed asLAN edge devices of the Security Fabric. FortiOS documentation states that FortiAPs and FortiSwitches appear in the Fabric topologyonly when connected on an interface with Security Fabric Connection enabled.

If the VLAN/AP management interface lacksSecurity Fabric Connection:

FortiGate does not treat that network as aFabric connection segment.

CAPWAP discovery from FortiAPs on that VLAN will not result in the AP being onboarded and shown for management.

Therefore the key misconfiguration is:

✔A – Security Fabric is disabled on the VLAN interface used for AP management.

Why the others are not the root cause:

B. Firmware incompatibility– would usually show as a “Managed (upgrade required)” or similar status after discovery, not complete non-detection. The scenario specifically points to a configuration issue, not firmware.

C. VLAN not tagged correctly on uplink– The FortiSwitch uplink to FortiGate is the FortiLink trunk, and the VLAN sub-interface APs is already bound to fortilink, so tagging on the uplink is correct by definition.

D. CAPWAP ports not open– CAPWAP (UDP 5246/5247) is terminated locally on FortiGate and does not depend on any firewall policy; these ports are open on the FortiGate itself by default.

Context: You’re troubleshootingSyslog-based SSOonFortiAuthenticator:

Devices (typically firewalls, WLAN controllers, VPN gateways) sendsyslog messagescontaining usernames, IPs, login/logout events.

FortiAuthenticator parses those logs usingSyslog SSO rulesand injects logon sessions intoFSSOfor FortiGate.

When users are not mapping correctly, you need to see:

Did the syslog message arrive?

Which matching rule (if any) caught it?

What username and IP were extracted?

Why was a message ignored or rejected?

FortiAuthenticator has a dedicated debug area for this:

Debug logs → Single Sign-On → Syslog SSO

This view shows:

Raw syslog lines received

Thematching ruleapplied (or “no match”)

Parsed fields (username, IP, group)

Any parsing errors

This is exactly the tool designed totroubleshoot and diagnose Syslog SSO issues.

Why the other options are not the best for this issue

A. Debug logs > Remote Servers > Syslog Viewer

Lets you see syslog traffic in general, but doesnotshow how SSO rules are applied or why they fail. Good for connectivity checks, not SSO logic.

B. Parsing Test Tool

Useful totestpatterns and rules manually by pasting sample log lines, but it doesn’t show live traffic or running SSO sessions.

C. Debug logs > SSO Sessions page

Shows existing SSO sessions (who is logged in), but notwhya particular syslog message did not create a session.

FortiLink NACis the NAC (Network Access Control) engine built into FortiGate when it manages FortiSwitch devices.

It performs:

✔Automated device onboarding

Automatically detects new devices connecting to switches.

Uses MAC, vendor, DHCP fingerprinting, or IoT database to classify devices.

No manual VLAN assignment required.

✔Security posture verification

Works with FortiClient EMS, ZTNA tags, IoT detection.

Applies policies based on:

Device type

User role

Endpoint compliance

IoT vulnerability status

✔Dynamic VLAN assignment

Automatically moves devices into proper VLANs, quarantine networks, or guest zones.

✔Integration with LAN Edge & Zero Trust

Uses FortiGate + FortiSwitch + FortiAP to enforce zero-trust access.

This matches the LAN Edge 7.6 Architect explanation of FortiLink NAC.

❌Why other answers are wrong

A. Extend security policies across FortiGate firewalls

Not NAC. That refers to Security Fabric or SD-WAN.

C. Apply manual firewall rules

FortiLink NAC is specifically designed toautomateaccess control.

D. Manually place devices in VLANs

NAC eliminates manual VLAN assignment — it is dynamic.
